LINE IN, SINGLE-ENDED /ANALOG AUDIO OUTPUT

• THD (20Hz – 20kHz)
• <0.001% at 2V out
• Signal-to-Noise Ratio
• >105dB (IHF; A-weighted, ref. 500mV out, unity gain)
• Channel separation
• >120dB (1 kHz)
• >108 dB (10 kHz))
• Input Impedance (R and C)
• 56 kohms + 100 pF
• Maximum input signal
• >5.6Vrms (ref. 0.1% THD)
  >8 Vrms (Analog Bypass)
• Output impedance
• Source Impedance + 22 Ohm
• Input sensitivity
• 185mV (ref. 500mV out, Volume maximum)
• Frequency response
• ±0.2dB (20Hz – 20kHz)
  ±0.2dB (Analog Bypass, 20Hz – 20kHz)
• Maximum voltage output
• -IHF load >5V (ref. 0.1% THD)
  >10 V (Analog Bypass, ref. 0.1% THD)

BALANCED IN, BALANCED /ANALOG AUDIO OUTPUT

• THD (20Hz – 20kHz)
• <0.001% at 2V out
• Signal-to-Noise Ratio
• >105dB (200 Ohm source; A-weighted, ref. 500mV out)
• Channel Seperation
• >120dB (1 kHz)
• >120 dB (10 kHz)
• Input impedance
• (R and C) 56 kOhms + 100 pF
• Maximum input signal
• >5.6 Vrms (ref. 1% THD)
  >8 Vrms (Analog Bypass, ref. 1% THD)
• Output impedance Source Impedance
• + 22 Ohms
• Input sensitivity
• 92.5mV (ref. 500 mV out, Volume maximum)
• Frequency response
• ±0.2 dB (20 Hz – 20 kHz)
  ±0.2 dB (Analog Bypass, 20 Hz – 80 kHz)
• Maximum voltage output (IHF load)
• >10 V (ref. 0.1 % THD)
  >20 V (Analog Bypass, ref. 0.1 % THD)

DIGITAL SOURCE IN, SINGLE-ENDED /ANALOG AUDIO OUTPUT

• THD (20Hz – 20kHz)
• <0.0005% at 2V out
• Signal-to-Noise Ratio
• >108 dB (IHF; A-weighted, ref. 500 mV out, unity gain)
• Channel separation
• >126dB at (1kHz)
• >115dB (10 kHz)
• Input sensitivity
• -20.25 dBFS (ref. 500 mV out (-6 dBV), max Volume
• Frequency response
• ±0.2 dB (20 Hz – 20 kHz)
• Maximum voltage output
• -IHF load >5 V (ref. 0.1 % THD)

DIGITAL SOURCE IN, BALANCED /ANALOG AUDIO OUTPUT

• THD (20 Hz – 20 kHz)
• <0.0005% at 2V out
• Signal-to-Noise Ratio
• >80 dB (IHF; A-weighted, ref. 500 mV out, unity gain)
• Channel Separation
• >126 dB (1 kHz)
• >115 dB (10 kHz)
• Input sensitivity
• -26.25 dBFS (ref. 500 mV out(-6 dBV), max Volume
• Frequency response
• ±0.2 dB (20 Hz – 20 kHz)
• Maximum voltage output (IHF load)
• >10 V (ref. 0.1 % THD)

LINE IN, SINGLE-ENDED/SUBWOOFER OUTPUT/2SUBWOOFERS

• THD (20 Hz – 20 kHz)
• <0.005% at 2V out
• Signal-to-Noise Ratio
• >84 dB (IHF; A-weighted, ref. 500 mV out, unity gain)
• Output impedance
• 480 Ohms
• Maximum voltage output
• -IHF load >5 V (ref. 0.1% THD

BALANCED IN, BALANCED /SUBWOOFER OUTPUT/2SUBWOOFERS

• THD (20 Hz – 20 kHz)
• <0.005% at 2V out
• Signal-to-Noise Ratio
• >80B (IHF; A-weighted, ref. 500 mV out, unity gain)
• Output impedance
• 480 Ohms
• Maximum voltage output
• -IHF load >10 V (ref. 0.1 % THD)

PHONO INPUT, SINGLE-ENDED /ANALOG AUDIO OUTPUT (Analog bypass)

• THD (20 Hz – 20 kHz)
• MM: <0.008% (ref. 2 V out)
  MC: <0.02% (ref. 2 V out)
• Signal-to-Noise Ratio
• MM: >82dB (A-weighted, ref. 500 mV out)
  MC: >75dB (A-weighted, ref. 500 mV out)
• Input Impedance (R and C)
• MM: 56 kohms + 100 pF
  MC: 100 ohms + 280 pF
• Input sensitivity
• MM: 1.7 mV (ref. 500 mV out, Volume maximum)
  MC: 123 μV (ref. 500 mV out, Volume maximum)
• Frequency response
• ±0.2 dB (20 Hz – 20 kHz)
• Maximum input signal at 1kHz
• MM: >80 mVrms
  MC: >7 mVrms (ref. 0.1 % THD)

LINE INPUT, HEADPHONE OUT(Analog Bypass)

• THD (20 Hz – 20 kHz)
• <0.002% (ref. 1V out)
• Signal-to-Noise Ratio
• >98 dB (32 ohms loads; A-WTD, ref. 0.5V out, unity gain)
• Frequency response
• ±0.3 dB (20 Hz – 20 kHz)
• Channel separation
• >62 dB at 1kHz
• Output impedance Source
• Z + 4.7ohms
• Maximum input signal at 1kHz
• MM: >80 mVrms
• Power consumption
• at Auto Standby ON and Network Standby OFF 0.5 W*
  at Auto Standby ON and Network Standby ON 2.0 W**
  OFF mode (Power switched OFF) 0.1 W
