Overview
Ortofon SPU Classic N Moving Coil Phono Cartridge
Nude Spherical stylus. Classic SPU sound. Headshell-free design.
The Ortofon SPU Classic N delivers the traditional SPU listening experience in a cartridge supplied without an integrated headshell. It retains the moving coil generator and Nude Spherical stylus design of the SPU Classic G family while offering an alternative mounting arrangement for compatible tonearms.
Its 18 µm Nude Spherical diamond, high-purity oxygen-free copper coils, and low-impedance generator preserve the SPU's established design. The cartridge produces a 0.2 mV output and uses a recommended tracking force of 4.0 grams.
The Classic N is designed for vintage SPU-type headshells or installation on a conventional headshell using Ortofon's separately available SPU N adapter.
Key Features
-
Nude Spherical stylus: 18 µm diamond profile.
-
Classic SPU generator: Low-output moving coil design with 0.2 mV output.
-
Headshell-free construction: Supplied without the integrated G-style headshell.
-
Flexible mounting options: Compatible with appropriate vintage SPU headshells or the SPU N adapter.
-
High-purity copper coils: Oxygen-free copper winding material.
-
Low internal impedance: 2 Ω, with a recommended 10 Ω load.
-
13 g cartridge weight: Excludes the weight of a separate headshell or adapter.
Complete Technical Specifications
|
Specification |
Ortofon SPU Classic N |
|---|---|
|
Cartridge type |
Moving coil (MC), stereo |
|
Mounting configuration |
Headshell-free SPU cartridge |
|
Conventional headshell installation |
Requires SPU N adapter |
|
Stylus type |
Nude Spherical |
|
Stylus tip radius |
R 18 µm |
|
Output voltage at 1 kHz, 5 cm/sec |
0.2 mV |
|
Channel balance at 1 kHz |
1 dB |
|
Channel separation at 1 kHz |
20 dB |
|
Channel separation at 15 kHz |
Greater than 10 dB |
|
Frequency response, 20 Hz–20 kHz |
±3 dB |
|
Tracking ability at 315 Hz |
60 µm |
|
Dynamic lateral compliance |
8 µm/mN |
|
Tracking force range |
3.0–5.0 g (30–50 mN) |
|
Recommended tracking force |
4.0 g (40 mN) |
|
Tracking angle |
20° |
|
Internal impedance / DC resistance |
2 Ω |
|
Recommended load impedance |
10 Ω |
|
Coil wire material |
High-purity oxygen-free copper (OFC) |
|
Cartridge color |
Matte black |
|
Cartridge weight |
13 g |
What Makes the SPU Classic N Different?
The Classic N offers the essential SPU Classic design without the integrated headshell found on the G-series models.
|
Feature |
SPU Classic N |
SPU Classic G MkII |
|---|---|---|
|
Headshell |
Not included |
Integrated G-style |
|
Stylus |
Nude Spherical |
Nude Spherical |
|
Stylus radius |
18 µm |
18 µm |
|
Output voltage |
0.2 mV |
0.2 mV |
|
Recommended tracking force |
4.0 g |
4.0 g |
|
Cartridge weight |
13 g |
30 g, including headshell |
Compatibility & Installation
Important: The SPU Classic N does not include a headshell and cannot be mounted directly to a conventional ½-inch headshell without an adapter.
It is intended for compatible vintage SPU-type headshells or use with Ortofon's SPU N adapter, which allows installation on a conventional headshell. Ortofon notes that vintage SPU-type headshells are no longer available new.
The cartridge's low compliance and recommended 4.0 g tracking force make tonearm compatibility important. Its 0.2 mV output also requires a suitable moving coil phono stage or properly matched step-up transformer.
Discover Ortofon at The Grid HiFi. Our Houston team can assist with SPU cartridge selection, mounting compatibility, and moving coil phono stage matching.
