IsoAcoustics GAIA II Neo | Speaker Isolation Feet

The IsoAcoustics GAIA II Neo brings the next generation of IsoAcoustics speaker isolation to floorstanding loudspeakers and subwoofers weighing up to 120 lbs (54 kg) per set of four. Positioned between the GAIA I Neo and GAIA III Neo, it is sized for a broad range of premium floorstanding speakers while adding significant usability improvements over the original GAIA II. IsoAcoustics

Refined GAIA Neo Isolation Technology

GAIA II Neo builds on IsoAcoustics' patented isolation architecture with redesigned internal isolators.

Changes to the isolator's shape, thickness and durometer were developed through additional research and performance testing. IsoAcoustics states that the resulting Neo design provides improvements in clarity, focus and low-frequency definition while retaining the fundamental mechanical isolation principles of the original GAIA Series. IsoAcoustics

The isolators are engineered to reduce vibration traveling between the loudspeaker and supporting surface while resisting lateral movement and maintaining stable speaker positioning.

Tool-Free Height Adjustment

GAIA II Neo provides up to 0.34 inches (8.5mm) of integrated height adjustment.

Rotating the lower adjustment ring raises or lowers the isolator without affecting its on-axis alignment. This makes leveling the loudspeaker significantly easier and allows the installer to compensate for uneven floors and achieve more consistent loading across the four isolators. IsoAcoustics

Simplified Flush-Fit Installation

The Neo design replaces the original GAIA's traditional lock-nut arrangement with a cleaner integrated O-ring system.

The O-ring compresses against the loudspeaker base to help create a strong connection while allowing the isolator to be correctly oriented. Logos positioned on both sides make proper alignment easier during installation. IsoAcoustics

GAIA II Neo must be connected to a threaded insert and is intended to replace the loudspeaker's existing spikes or threaded feet.

120-Pound Capacity

GAIA II Neo supports floorstanding speakers and subwoofers weighing up to 120 lbs (54 kg) per set of four.

This places it in the heart of the GAIA Neo range and makes it suitable for a wide variety of substantial high-performance loudspeakers without requiring the physically larger GAIA I Neo. IsoAcoustics

IsoAcoustics recommends remaining within the specified weight capacity because the rating represents the intended performance range of the isolation system.

Included Thread Adapters

GAIA II Neo includes:

• M8-1.25
• M6-1.0
• ¼"-20

Alternative thread adapters are available separately when required. IsoAcoustics

Easier Speaker Positioning

Optional IsoAcoustics Floor Sliders allow speakers fitted with GAIA Neo isolators to be moved more easily during setup.

They can be used directly on carpet or fitted with adhesive felt pads for hard flooring. Once speaker positioning and toe-in are finalized, the sliders can be removed while leaving the GAIA Neo isolators directly coupled to the supporting surface. IsoAcoustics

GAIA II Neo Technical Specifications

IsoAcoustics GAIA II Neo at The Grid HiFi

The IsoAcoustics GAIA II Neo combines the proven concept behind the original GAIA with improved internal isolation, adjustable height, simplified installation and a more contemporary design. Its 120-lb capacity makes it an excellent fit for a wide range of premium floorstanding loudspeakers and subwoofers.

At The Grid HiFi in Houston, Texas, we can help match the correct GAIA Neo model and thread adapter to your specific loudspeaker, ensuring the isolators are properly sized and installed for the system.
