Overview
Audio Research DAC9 Tube Digital-to-Analog Converter
Vacuum-Tube DAC • PCM to 384 kHz • DSD & 2xDSD • Quad DAC Architecture • Fully Balanced Class A Analog Stage
Complimentary White Glove Delivery • Travel Reimbursement*
The Audio Research DAC9 combines high-resolution digital conversion with the company's vacuum-tube analog architecture. It supports PCM up to 384 kHz, DSD and 2xDSD, while a pair of 6H30 dual-triode tubes handles the analog output stage. audioresearch.com
Quad DAC Architecture
Audio Research uses four D/A converters, with dual stereo DACs operating in mono for each channel. This architecture is designed to increase dynamic range and lower the noise floor. Separate signal paths handle PCM and native DSD data, avoiding unnecessary conversion between formats. audioresearch.com
6H30 Tube Analog Stage
The DAC9's digital section feeds a fully balanced, Class A, zero-feedback analog stage using two 6H30 tubes. The circuit is direct coupled without capacitors in the signal path. audioresearch.com
Flexible Digital Connectivity
An asynchronous USB 2.0 input supports PCM from 44.1 to 384 kHz plus DSD and 2xDSD. Additional galvanically isolated RCA, BNC and AES/EBU XLR inputs support up to 192 kHz, while Toslink supports up to 96 kHz. Selectable fast and slow digital filters provide additional playback flexibility. audioresearch.com
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Tube Digital-to-Analog Converter |
| DAC Resolution | 24-Bit |
| USB | 44.1 to 384 kHz, DSD, 2xDSD |
| RCA / BNC / AES-EBU XLR | 44.1 to 192 kHz |
| Toslink | 44.1 to 96 kHz |
| Upsampling | Up to 384 kHz |
| Digital Filters | Selectable Fast / Slow |
| Tube Complement | 2 × 6H30 Dual Triodes |
| Analog Circuit | Balanced Class A, Zero Feedback |
| Frequency Response | ±0.15 dB, 20 Hz to 20 kHz |
| Extended Response | ±3 dB, 6 Hz to 192 kHz |
| THD + Noise | <0.002% at 2V RMS, 1 kHz Balanced |
| Signal-to-Noise Ratio | >114 dB |
| Channel Separation | 107 dB |
| Intrinsic Jitter | <10 pS |
| Balanced Output | 3.8V RMS Maximum |
| Single-Ended Output | 1.9V RMS Maximum |
| Output Impedance | 500Ω Balanced / 250Ω SE |
| Power Consumption | 60W Maximum |
| Standby | <2W |
| Dimensions | 19" W × 7" H × 15.5" D |
| Weight | 32 lb |
| Manufacturing | Handcrafted and Auditioned in Minnesota, USA |
