Overview
Ortofon SPU Classic N E Moving Coil Phono Cartridge
Nude Elliptical stylus. Classic SPU design. Headshell-free construction.
The Ortofon SPU Classic N E brings the traditional SPU moving coil design to a cartridge supplied without an integrated headshell. It shares the sound reproduction characteristics of the SPU Classic G E series while offering a different mounting configuration.
Its Nude Elliptical diamond stylus features an 8/18 µm profile designed for detailed groove tracing and expansive stereo imaging. The cartridge combines high-purity oxygen-free copper coils with a low-impedance generator producing 0.2 mV output.
The SPU Classic N E can be installed in a compatible vintage SPU-type headshell or mounted to a conventional headshell using Ortofon's separately available SPU N Adapter.
Key Features
-
Nude Elliptical stylus: 8/18 µm diamond profile for detailed stereo reproduction.
-
Classic SPU generator: Low-output moving coil design delivering 0.2 mV.
-
Headshell-free construction: Supplied without an integrated G-style headshell.
-
Flexible mounting: Compatible with suitable vintage SPU headshells or the optional SPU N Adapter.
-
High-purity copper coils: Oxygen-free copper winding material.
-
Low internal impedance: 2 Ω, with a recommended 10 Ω load.
-
60 µm tracking ability: Measured at 315 Hz.
-
13 g cartridge weight: Excludes a separate headshell and adapter.
Complete Technical Specifications
|
Specification |
Ortofon SPU Classic N E |
|---|---|
|
Cartridge type |
Moving coil (MC), stereo |
|
Mounting configuration |
Headshell-free SPU cartridge |
|
Conventional headshell installation |
Requires SPU N Adapter |
|
Stylus type |
Nude Elliptical |
|
Stylus tip radius |
r/R 8/18 µm |
|
Output voltage at 1 kHz, 5 cm/sec |
0.2 mV |
|
Channel balance at 1 kHz |
1 dB |
|
Channel separation at 1 kHz |
20 dB |
|
Channel separation at 15 kHz |
Greater than 10 dB |
|
Frequency range at −3 dB |
20 Hz–25 kHz |
|
Frequency response, 20 Hz–20 kHz |
+3 / −2 dB |
|
Tracking ability at 315 Hz |
60 µm |
|
Dynamic lateral compliance |
8 µm/mN |
|
Tracking force range |
3.0–5.0 g (30–50 mN) |
|
Recommended tracking force |
4.0 g (40 mN) |
|
Tracking angle |
20° |
|
Internal impedance / DC resistance |
2 Ω |
|
Recommended load impedance |
10 Ω |
|
Coil wire material |
High-purity oxygen-free copper (OFC) |
|
Cartridge color |
Matte black |
|
Cartridge weight |
13 g |
SPU Classic N vs. SPU Classic N E
Both cartridges use the same headshell-free SPU mounting arrangement, moving coil output, and recommended tracking force. The principal difference is the stylus profile.
|
Specification |
SPU Classic N |
SPU Classic N E |
|---|---|---|
|
Stylus |
Nude Spherical |
Nude Elliptical |
|
Stylus radius |
18 µm |
8/18 µm |
|
Output voltage |
0.2 mV |
0.2 mV |
|
Tracking ability |
60 µm |
60 µm |
|
Recommended tracking force |
4.0 g |
4.0 g |
|
Dynamic compliance |
8 µm/mN |
8 µm/mN |
|
Cartridge weight |
13 g |
13 g |
The Classic N E's elliptical stylus is designed to retrieve additional groove detail and produce more expansive imaging. The spherical Classic N retains the traditional stylus geometry associated with the original SPU design.
Compatibility & Installation
Important: The SPU Classic N E does not include a headshell. It cannot be mounted directly to a conventional ½-inch headshell without the appropriate adapter.
Ortofon's SPU N Adapter allows the cartridge to be fitted to a traditional headshell. The adapter is made from aluminum, weighs 2.9 grams, and is sold separately.
The cartridge's low compliance and recommended 4.0 g tracking force make tonearm matching important. Its 0.2 mV output requires a suitable moving coil phono stage or appropriately matched step-up transformer. Ortofon specifies a recommended load impedance of 10 Ω.
Discover Ortofon at The Grid HiFi. Our Houston team can assist with SPU cartridge selection, mounting compatibility, and moving coil phono stage matching.
